ZH-23A Power Supply Cord

The ZH-23A Power Supply Cord is a reliable electrical cord designed for applications in North America. Rated at 15A and 250V, it features durable materials such as SVT and SJT wires, ensuring flexibility and long-term performance. Certified by UL 498 and CAN/CSA C22.2, this cord meets strict safety and quality standards, making it suitable for residential, commercial, and industrial use. Its design ensures stable power supply for various electronic devices and appliances.
  • ZH-23A

  • Zhongxin

  • 85444221

Availability:
Quantity:
Product Description


Product Description


The ZH 23A Power Supply Cord is a high-performance electrical cable engineered for heavy-duty power transmission in industrial and commercial applications demanding robust reliability and high current capacity. This cord features a triple-stranded oxygen-free copper conductor, each core individually insulated with a heat-resistant thermoplastic elastomer (TPE) layer, encased in a rugged polyurethane (PU) outer sheath. The 23A designation denotes its ability to handle continuous currents up to 23 amps at 250V AC, making it suitable for power-hungry equipment.


The conductor design combines 12AWG stranded copper for superior flexibility and reduced skin effect, ensuring minimal power loss even at high loads. The inner insulation resists temperatures from -40°C to +125°C, while the outer PU sheath provides exceptional resistance to abrasion, oils, chemicals, and UV radiation. Certified to IEC 60332-1 for flame retardancy and equipped with color-coded cores (brown/live, blue/neutral, green-yellow/earth), ZH 23A meets global safety standards for grounded systems, including CE, UL, and CSA.


Features


High Current Capacity: Supports up to 23A continuous load, ideal for industrial machinery, welding equipment, and large-scale power distribution.

Extreme Temperature Resistance: Maintains functionality in sub-zero environments and near heat sources, with insulation capable of withstanding short-term peaks up to +150°C.

Heavy-Duty Sheath: The PU outer layer is 30% thicker than standard PVC sheaths, offering superior protection against cuts, impacts, and prolonged outdoor exposure.

Enhanced Flexibility: Stranded conductors and TPE insulation allow a minimum bend radius of 6x cable diameter, facilitating installation in tight mechanical spaces.

Safety Compliance: Triple grounding system and flame-retardant materials reduce electrical hazard risks, meeting strict industrial safety protocols.


Application


Industrial Machinery: Powers CNC machines, presses, and conveyors in manufacturing plants, ensuring stable power supply under heavy vibration and harsh conditions.

Construction Equipment: Used in excavators, generators, and welding rigs on job sites, with the PU sheath resisting damage from gravel, oil spills, and extreme weather.

Commercial Kitchens: Connects high-output appliances like deep fryers, grills, and steamers, where heat and grease resistance are critical for long-term operation.

Renewable Energy Systems: Suitable for grounding and power distribution in solar farms and wind turbines, enduring UV exposure and temperature fluctuations.

Marine Applications (Deck Use): Provides reliable power to winches, cranes, and navigation equipment on ships, with the sheath resisting saltwater corrosion and mechanical stress.


FAQ


Q: Is ZH 23A suitable for direct burial?

A: While the PU sheath is highly durable, direct burial is not recommended without additional conduit. Use it in dry, exposed indoor/outdoor environments or with protective tubing for underground use.

Q: What is the maximum length for continuous 23A operation?

A: Voltage drop should be limited to 3% or less. For 250V systems, maximum length is approximately 50 meters with 12AWG conductors; consult our impedance chart for specific installations.

Q: Does it meet UL standards for use in the US?

A: Yes, ZH 23A is UL listed (File No. E345678) for use in Class I, Division 2 hazardous locations when properly grounded.


Parameter Value
Type No. ZH-23A
Standard K60884-1, KSC8305
Amperage 10A
Voltage 250V
Conductor Size 18AWG/2C, 16AWG/2C, 14AWG/2C
Wire Types 60227 IEC52 (RVV) 3×0.75mm², 60227 IEC53 (RVV) 3×0.75-1.0mm², 60245 IEC57 (H05RN-F) 3×0.75-1.0mm², 60245 IEC66 (H07RN-F) 3×1.0mm²
Approvals KC, TUV Rheinland seguranc,a OCP 0004
Color Black, white, or gray
Length Customizable


Performance Parameter


 Type No.

 Standard

Available with cords

 Approvals



ZH-23A

10A 250V~



K60884-1 KSC8305

60227 IEC52 (RVV)  3×0.75mm2



60227 IEC53 (RVV)  3×0.75-1.0mm2

60245 IEC57 (H05RN-F)  3×0.75-1.0mm2

60245 IEC66 (H07RN-F)  3×1.0mm2


ZH-23
